High efficiency milling cutter for cast iron. Cutting edge specially designed for chip control of iron sheeting and soft steel processing
Reduce unexpected chipping Shock interruption and damage to steel pipes, rolled steel, and low carbon steel.
1. Reduce chipping of the knife edge with a raised spine.
2. The ridge on the front of the knife is high to improve chip breaking.
3. Variable slope design within the knife tip radius increases chip distortion and improves chip breakage.
| Inserts | DCMT11T308N-FB (T3000Z) |
|---|---|
| Conditions Cutting |
vc=200 m/min, f=0.03, 0.04, 0.05mm/rev ap=0.50 to 0.60 mm wet |
| Inserts | DCMT11T308N-FB (T1500Z) |
|---|---|
| Conditions Cutting |
vc=360 m/min, f=0.14mm/rev, ap=0.30mm(rough) 0.02mm(finish), wet |
| Inserts | TPMT110304N-FB (T3000Z) |
|---|---|
| Conditions Cutting |
vc=200 m/min, f=0.09 mm/rev, ap=0.25 mm, wet type |
| Inserts | DCMT11T308N-FB (T3000Z) |
|---|---|
| Conditions Cutting |
vc=200 m/min, f=(1)0.08 mm (2)0.10 mm/rev, ap=(1)0 to 0.50 mm (2)0.50 mm, wet type |
| Inserts | DCMT11T308N-FB (T3000Z) |
|---|---|
| Conditions Cutting |
vc=250 m/min, f=0.15mm/rev(drilling, internal faceting) 0.10 mm/rev(rounded corner), ap=0.25 mm, wet type |
| Inserts | DCMT11T304N-FB (T1500Z) |
|---|---|
| Conditions Cutting |
vc=220 m/min, f=(1)0.15 mm (2)0.12 mm (3)0.18 mm/rev, ap=0.25 mm, wet type |
